Description
Technical Spec:
• Band Width – 12mm
• Capacity (min – max) – Ø 23-35mm
• Tightening Torque (max) – 5.0Nm (1)
• Screw Housing Length – 24mm
• Grade W4 – Stainless Screw, Band & Housing (2)
• Corrosion Resistance (min.Hour) IS0 9227 – 240
• Screw Head – FL | 7mm Hex
(1) Recommended tightening torque. Recommended tightening speed 300 – 350 rpm
(2) Screw – 1.4567 Stainless DIN EN-10088-3 or equivalent | Housing & Band – 1.4301 Stainless DIN EN-10088-2 or equivalent
KALE is certified with ISO TS 16949, ISO 9001, ISO 14001 management systems as per the expectations of the global automotive industry.
